| Place of Origin: | CHINA |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA45DD |
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Boxes, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1 1/2'' | Valve Series: | DD |
|---|---|---|---|
| Valve Structure: | Right Angle, Dresser Nut | Diaphragm Material: | NBR, FKM |
| Working Pressure Range: | 0.35 To 0.85 MPa | Voltage: | AC220V, AC110V, AC24V, DC24V |
| Body Material: | Aluminum (Diecast) | Application: | Dust Collector |
| Highlight: | Goyen Pulse Jet Valve CA45DD,Pulse Jet Valve Dresser Nut,1/2" Goyen Pulse Valve |
||
CA45DD G1 1/2" Goyen Type Dresser Nut Pulse Jet Valve For Dust Collector
CA45DD /CA45DD010-300 / CA45DD010-305 /CA45DD000-301 type pulse jet valves . It is compression fitting pipe version, there are fixed nut at both ends which make it easy to install and use the valve.
It is also right angle with the 90° angle between the inlet and outlet, & solenoid control, 2-way dust collector valve used for pulsing large volumes of air into filter bags for particulate removal.
Technical Data of DD Series Pulse Jet Valves:
|
Model No
|
CA20DD
|
CA25DD
|
CA45DD
|
|
Port Size
|
3/4''
|
1''
|
1 1/2''
|
|
Pipe Connection
|
Dresser Nut
|
||
|
Diaphragm Number
|
1
|
1
|
2
|
|
Working Pressure Range
|
0.35 to 0.85 MPa (5 to 125 PSI)
|
||
|
Diaphragm Material
|
NBR, VITON
|
||
|
Valve Body Material
|
Aluminum (Diecast)
|
||
Ordering Code of DD Series Pulse Jet Valve:
