| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | DIN43650B |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 1000000 pcs per month |
| Product Name: | DIN 43650 Connector | DIN 43650 Type: | DIN43650B |
|---|---|---|---|
| Protection Class: | IP65 | Pole Format: | 2+1GND, 3+1GND |
| Distance: | 11mm | Fixing Screw: | M3x30 |
| Max Conductor Section: | 3x1.5mm² | Current Rating: | 10A |
| Contact Resistance: | ≤5mΩ | Working Voltage: | AC380V, DC300V |
| Highlight: | DIN 43650 Form B Solenoid Coil Connector,MPM Solenoid Coil Connector,EN 175301-803 Form B |
||
DIN 43650 Form B MPM Solenoid Coil Connector With LED Light Indicator
The MPM range of DIN 43650 connectors is used extensively to provide electrical connections in a wide range of applications. The most common application for mPm connectors is in conjunction with hydraulic, pneumatic or electro magnetic devices including solenoid valves. DIN 43650 solenoid connectors are available in three formats: Form A, Form B or Form C. They're made to function within certain voltage limits. There are also three gasket options available for DIN connectors: NBR Profile, NBR Flat or EPDM Flat, each with different characteristics. While NBR rubber is an oil-resistant material, EPDM rubber isn't as resilient against oils but can cope better with ozone, heat and adverse weather conditions.
Technical Data of DIN43650B Solenoid Valve Connector:
|
DIN 43650 Type
|
DIN 43650 Form B
|
|
Termination Method
|
Screw
|
|
Contact Spacing
|
11mm
|
|
Number of Poles
|
2 Poles + Ground, 3 Poles + Ground
|
|
Current Rating
|
10A
|
|
Contact Resistance
|
≤5mΩ
|
|
Fixing Screw
|
M3x30mm
|
|
Max Conductor Size
|
3x1.5mm²
|
|
Gasket
|
NBR
|
|
Protection Class
|
IP65
|
|
Working Voltage
|
AC380V, AC220V, AC110V, AC24V, DC24V, DC12V
|
Dimension of DIN43650B Solenoid Coil Connector:
Product Video of DIN43650B Solenoid Valve Connetor:
