| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | DIN43650A-CB |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic Bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 50000pcs per month |
| Product Name: | Connector | Protection Class: | IP67 |
|---|---|---|---|
| Type: | DIN43650A | Pole No: | 2P+E, 3P+E |
| Contact Distance: | 18mm | Working Voltage: | AC DC |
| Led Indicator: | With | Cable Length: | 1 Meter (can Be Customized) |
| Highlight: | DIN 43650 From A Solenoid Valve Connectors,IP67 Solenoid Valve Connectors,Molex Type DIN Valve connectors |
||
DIN 43650 From A IP67 Solenoid Valve Connectors with Molded Cable
BRANDO produces DIN 43650 connectors and other special style connectors. DIN 43650 connectors are commonly used to supply power to solenoid valves, which widely used in Hydraulic, Pneumatic, Electrical Appliance industry, etc.
Features:
1. Wide range of DIN43650 industry standard form A, B, C types, special on request
2. Protection class: IP65, IP67
3. Multiple connector circuits specifications for optional, LED; LED/VDR; Rectifier
4. A variety shell color: black, brown and transparent
Technical Data:
| DIN Type | DIN43650A |
| Contact Distance | 18mm |
| Number of Poles | 2 Poles + Ground, 3 Poles + Ground |
| Nomical Current | 10A |
| Contact Resistance | ≤5mΩ |
| Fixing Screw | M3x30mm |
| Max Conductor Size | 3x1.5mm² |
| Protection Class | IP67 |
| Working Voltage | AC, DC |
| Cable Length | 1 meter (can be customized) |
Main Dimension:
More DIN 43650 Connectors:
|
|
|
| DIN43650A | DIN43650B | DIN43650C |
|
|
|
| Waterproof | With Cable | Other |
