24VDC Solenoid Valve For Afimilk MPC Fullwood LM1 Afiflo 2000 Milk Meter

24VDC Solenoid Valve For Afimilk MPC Fullwood LM1 Afiflo 2000 Milk Meter

This solenoid valve is popularly used in milk meter like Afimilk MPC, Fullwood LM1, Afiflo 2000, etc. You have to connect the solenoid valve ports to vacuum and clean air. When the solenoid valve is energized, vacuum from the solenoid line causes the silicon diaphragm to pull the valve down. This releases a portion of the milk.

How to work?

1. Milk meter solenoid valve is plugged at a socket in the lower cover of the milk meter. The solenoid valve has two ports – for vacuum and exhaust.

2. Connect the solenoid valve to the vacuum line via the larger diameter port and to the clean air line via the smaller diameter port.

3. Connect each milk meter solenoid ports to their corresponding Vacuum/Air-line using the supplied flexible 1/4'' tube. Tube length should be as short and straight as possible, without unnecessary bends.

Main Dimension:

Our Production:

FAQ: How to choose a matching solenoid coil?

1. Voltage: The first thing to consider is the supply voltage of the solenoid valve, which is DC or AC.
2. Power or Resistance:
3. Dimension: Inner hole diameter, height and width.
4. Working Environment: temperature, humidity, indoor or outdoor, protection grade.
5. Connector Type: pin type, flying leads type, standard interface, etc.
6. Application: some special application areas require the use of specially designed solenoid coils, such as industries that require waterproof, must use IP67 or higher grade solenoid valve coils.
7. Other Requirements: such as environmental protection material requirements or certification.
