Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output

Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output

  • Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output
Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: BC-12-3
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 5000pcs per month
Contact Now
Detailed Product Description
Product Name: Pulse Controller Channel Number: 12
Input Voltage: 220VAC Output Voltage: 24VDC
Pulse Width: 0.01 To 99.99s Pulse Interval: 1 To 9999s
Cycle Interval: 1 To 9999s Application: Dust Collector
Highlight:

12 Channels Pulse Controller

,

Dust Collector Pulse Timer

,

Pulse Jet Controller

Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output



Pulse Controller is a pulse jet bag filter control device in cleaning system, its output signal to control Pulse Jet Valve, blow compressed air bag sequential cleaning, so dust remains in the design within a predetermined range, in order to protect the processing power and dust collecting effect.

1. Channel Number: the number of pulse valves in the equipment (off-line mode is the number of pulse valves in a single chamber);
2. Pulse Width: the working time of the pulse valve (blowing time);
3. Pulse Interval: the interval between 2 pulse valves;
4. Cycle Interval: the interval between the end of one cycle and the start of the next cycle;
Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output 0



Technical Data:

Model No BC-08 BC-10 BC-12 BC-16 BC-20 BC-24 BC-30 BC-36 BC-52 BC-64
Channel No 8 10 12 16 20 24 30 36 52 64
Input Voltage 24VDC, 110VAC, 220VAC, other can be customized
Output Voltage 24VDC, 24VAC, 110VAC, 220VAC, other can be customized
Pulse Width 0.1 to 999.9 Seconds
Pulse Interval 1 to 9999 Seconds
Cycle Interval 1 to 9999 Seconds
Working Environment 1. -25°C to +55°C
2. The relative humidity of the air does not exceed 85%
3. No serious corrosion gas and conductive dust
4. No violent vibration or shock


Detailed Images:

detail



Controller Setting:

setting



Controller Wiring:



wiring



Our Production:

Dust Collector Pulse Valve Timer Controller 12 Channels 220VAC Input 24VDC Output 4
