Focus on your demands
Offer you best solution
Sales & Support:
 |
| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BAPC211037301 |
| Minimum Order Quantity: | 200 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 sets per month |
| Product Name: | Pulse Valve Armature | Fitted Pulse Valve Port Size: | 3/4'', 1'' |
|---|---|---|---|
| Fitted Pulse Valve Model: | SCG353A043, SCG353A044 | Plunger Tube Material: | Stainless Steel |
| Seal Material: | NBR, VITON | 1 Set: | 1pc Plunger Tube, 1pc Iron Core, 1pc Spring |
| Highlight: | ASCO Pulse Jet Valve Armature,ASCO Pulse Jet Valve Plunger,ASCO Pulse Jet Valve Armature Plunger |
||
Solenoid Armature Plunger For ASCO Pulse Jet Valve SCG353A043 SCG353A044
This is a solenoid armature for asco pulse valve SCG353A043, SCG353A044. Pulse valves are operated by integral solenoid pilot operator. When the valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pilot operated valve is de - energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the valve.
Dimension & Data of Armature, Coil for ASCO Pulse Valve:
|
BRANDO Model
|
BAPC211037301
|
|
Plunger Tube Material
|
Stainless Steel
|
|
Seal Material
|
NBR, VITON
|
|
Fitted Pulse Valve Model
|
SCG353A043
SCG353A044 |
|
BRANDO Model
|
BB11036001
|
|
Voltage
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
|
Power
|
18VA, 20VA, 21VA, 28VA,
9W, 10W, 11W, 15W,
18W, 21W, 30W
|
|
Insulation Class
|
H, F
|
|
Temperature Class
|
T, B, F
|
|
Connector
|
DIN 43650 Form A
|
|
Fitted Pulse Valve Model
|
SCG353A043
SCG353A044 |
Video of SCG353A043, SCG353A044 Pulse Valve Armature:
BRANDO Solenoid Valve Armature Production Video:
More ASCO Type Pulse Jet Valve for you to choose:
|
|
|
|
| Threaded Type | Remote Pilot Type | Straight Through Type | Submerged Type |
|
|
|
|
| Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Mr. Brandon Bao
Tel: 86-13454729544
Fax: 86-574-83879820
