Parker Type 491514C2 24DC 16W Water Control Valve Coil F Class PN 439520 Connector For DIN43650A

Parker Type 491514C2 24DC 16W Water Control Valve Coil F Class PN 439520 Connector For DIN43650A

Encapsulated in synthetic Material, Connector For 2P+E DIN43650A PLUG. IP65 rate can be achieved using a DIN Plug connector only.

Solenoid valves dispense liquids and are for use in gas shutoff, vacuum holding, and tank draining. Solenoid valve coils convert electrical energy into linear motion to control the opening and closing of solenoid valves.

491514C2 Parker Type Solenoid Valve Spare Parts.

Part Number: 439520

Insulation Class:F

Voltage: 24DC

Power: 16W

The use of high pressure gases became a necessityin the new technologies developed during the last years.The control of these fluids can be done through the solenoid valves high pressure applications(maximum 50 bar).
The life expectancy of several millions of cycles, with response time of few milliseconds, allows the use of these valves on intensive applications and on high technology machines, as the plastic bottle blowing machines, or the laser cutting machines.

Technical data:

Dimension:

Details:

DIN 43650A Connector:

Parker Type Lucifer Valve Suitable for a wide variety of coffee machine :

BEZZERA Coffee machine ELLISSE
BRASILIA Coffee machine CENTURY, PORTOFINO
CONTI Coffee machine CLUB, TWINSTAR2, XEOS2
ESSIKA Coffee machine SK2, SSK2
FAEMA Coffee machine COMPACT, DUEA, E61, E91, EXPRESS
FIORENZATO C.S. Coffee machine MURANO
PAVONI Coffee machine BART
RANCILIO Coffee machine EPOCA
RENEKA Coffee machine LC, VIVA, VIVA S, XL-PALLAS
SAN MARCO Coffee machine EUROPA95, NS85

Features:

1. Using high quality wire;
2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be F, H;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
