| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BCSM-3T-Z-G |
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | PVC bag, then inner box, then carton, then pallet |
| Delivery Time: | 1 week after payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Hose Fittings | Type: | Male Banch Tee |
|---|---|---|---|
| Tube OD (Inch): | 1/8", 1/4", 3/8", 1/2" | Tube OD (Mertric): | 4mm, 6mm, 8mm, 10mm, 12mm |
| Material: | Brass | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | 0 To +60℃ | Connection: | Fast Twist |
| Highlight: | Fast Twist Pneumatic Hose Fitting,Pneumatic Tee Connector,Pneumatic T Connector |
||
Fast Twist Pneumatic Hose Fittings Male Banch Tee 3/8'' 1/2''
BRANDO - Specialist in CNC Machining Parts manufacturing, extensively offers a wide assortment of pneumatic fittings, air couplings, connectors and adapters. With the connection type and function performs, huge selection of all types of pneumatic fittings (air fittings) are available here, from push-on and push-in Fittings to connect couplings to pneumatic tubing fittings to flow control valves and accessories.
High quality CNC turned pneumatic air fittings of all kinds are offered to worldwide customers at the best prices in whole market! Our precision Pneumatic Fittings produced to your drawing with advanced machining technology including CNC lathes, CNC milling, CNC grinding, can be compatible with the rest of your Pneumatic system perfectly.
Technical data of Pneumatic Hose Fittings:
Specifications of Male Banch Tee Fast Twist Pneumatic Hose Fittings:
|
Model No
|
D
|
M
|
L1
|
L
|
L'
|
S
|
S1
|
|
BCSM-3T-Z2.5-G
|
4
|
M5X0.8
|
4
|
17
|
20
|
10
|
8
|
|
M6X1
|
4
|
20
|
10
|
||||
|
BCSM-3T-Z4-G
|
6
|
G1/8''
|
5
|
19
|
19
|
12
|
10
|
|
G1/4''
|
6
|
21
|
12
|
||||
|
G3/8''
|
7
|
23
|
14
|
||||
|
G1/2''
|
9
|
25
|
17
|
||||
|
BCSM-3T-Z6-G
|
8
|
G1/8''
|
5
|
22
|
19
|
12
|
13
|
|
G1/4''
|
6
|
21
|
12
|
||||
|
G3/8''
|
7
|
23
|
14
|
||||
|
G1/2''
|
9
|
25
|
17
|
||||
|
BCSM-3T-Z8-G
|
10
|
G1/8''
|
5
|
24
|
21
|
12
|
15
|
|
G1/4''
|
6
|
22
|
12
|
||||
|
G3/8''
|
7
|
24
|
14
|
||||
|
G1/2''
|
9
|
26
|
17
|
||||
|
BCSM-3T-Z10-G
|
12
|
G1/8''
|
5
|
25
|
21
|
14
|
17
|
|
G1/4''
|
6
|
23
|
14
|
||||
|
G3/8''
|
7
|
25
|
14
|
||||
|
G1/2''
|
9
|
27
|
17
|
Product Video of BRANDO Fast Twist Pneumatic Hose Fittings:
List of All Quick Twist Brass Pneumatic Hose Fittings:
Choosing the Right Fittings for Your Pneumatic System:
Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.
Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
