| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BCKH-JJ-Z4,BCKH-JJ-Z2.5,BCKH-JJ-Z6,BCKH-JJ-Z8,BCKH-JJ-Z10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 10000000pcs per month |
| Product Name: | Pneumatic Hose Fitting | Type: | Male Banjo |
|---|---|---|---|
| Tube OD (Inch): | 1/8", 1/4", 3/8", 1/2" | Tube OD (Mertric): | 4mm, 6mm, 8mm, 10mm, 12mm |
| Material: | Brass | Working Pressure Range: | 0 To 0.8MPa |
| Working Temperature: | 0 To +60℃ | Connection: | Push In |
| Highlight: | 4mm Brass Metal Pneumatic Hose Fitting,Push In Pneumatic Hose Fitting,Male Banjo Pneumatic Air Fitting |
||
Male Banjo Push In Tube Quick Connect Brass Metal Pneumatic Hose Fitting
Push-to-connect fittings have ends that are designed to accept tubing by pushing it into the end. These fittings typically disconnect via some type of collar retraction. Push to connect fittings are convenient for sections of the system requiring frequent disconnection and reconnection. BRANDO offers Push to Connect fittings in a variety of configurations; Male Connectors, Female Connectors, 90° Elbows, Unions and Tees, in many sizes and a variety of materials; Brass, Nickel Plated Brass, Composite and Plastic. If you don’t see the pneumatic fitting you are looking for please contact us and we can find a push to connect fittings product inventory that is customized to your specific needs.
Technical data of Pneumatic Hose Fittings:
Specifications of Male Banjo Brass Pneumatic Hose Fittings:
|
Model No
|
D
|
R
|
L1
|
L
|
L'
|
S
|
|
BCKH-JJ-Z2.5
|
4
|
M5X0.8
|
6
|
28
|
18
|
8
|
|
BCKH-JJ-Z4
|
6
|
M5X0.8
|
6
|
29
|
18
|
8
|
|
M6X1
|
6
|
29
|
18
|
8
|
||
|
M8X1
|
7
|
29
|
24
|
12
|
||
|
ZG1/8''
|
8
|
29
|
25
|
12
|
||
|
ZG1/4''
|
10
|
29
|
28
|
15
|
||
|
ZG3/8''
|
11
|
31
|
34
|
19
|
||
|
ZG1/2''
|
12
|
33
|
37
|
24
|
||
|
BCKH-JJ-Z6
|
8
|
M5X0.8
|
6
|
27
|
18
|
8
|
|
M6X1
|
6
|
27
|
18
|
8
|
||
|
M8X1
|
7
|
27
|
24
|
8
|
||
|
ZG1/8''
|
8
|
31
|
25
|
12
|
||
|
ZG1/4''
|
10
|
29
|
28
|
15
|
||
|
ZG3/8''
|
11
|
31
|
34
|
19
|
||
|
ZG1/2''
|
12
|
34
|
37
|
24
|
||
|
BCKH-JJ-Z8
|
10
|
ZG1/8''
|
8
|
33
|
28
|
12
|
|
ZG1/4''
|
10
|
32
|
31
|
15
|
||
|
ZG3/8''
|
11
|
34
|
36
|
19
|
||
|
ZG1/2''
|
12
|
36
|
37
|
24
|
||
|
BCKH-JJ-Z10
|
12
|
ZG1/8''
|
8
|
36
|
28
|
12
|
|
ZG1/4''
|
10
|
35
|
31
|
15
|
||
|
ZG3/8''
|
11
|
35
|
36
|
19
|
||
|
ZG1/2''
|
12
|
37
|
37
|
24
|
Product Video of BRANDO Brass Pneumatic Hose Fittings:
List of All Push To Connect Brass Pneumatic Hose Fittings:
Choosing the Right Fittings for Your Pneumatic System:
Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.
Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
